MIL-DTL-2845E (SH)
1.
Oil reservoir (expansion chamber).
2.
Inspection window for checking oil level.
3.
Flexible plastic pipe, clear.
4.
Blocking device, 3-5/32" * 3 5/32" (80 * 80mm) wood beams.
5.
Lengthwise sheathing 1-1/8" (30mm) wood planks.
6.
Diagonal 3-5/32" * 3-5/32" (80 * 80mm) wood beams.
7.
Oil-tight cover.
8.
Flooring 1-1/8" (30mm) wood planks.
9.
Cross-beams 5-33/64" * 5-33/64" (140 * 140mm).
10.
Exterior battens 1-3/16" * 4-23/32" (30 * 120mm).
FIGURE 17.
Hub packing (see 3.16.3).
51
